Midi Remote Beer Cooler – 6 Coil

The Midi Remote 6 Coil Beer Cooler is designed for multi-product draught beer dispense systems where reliable cooling is required between the keg or cellar and the dispense point.

Featuring six product cooling coils, a 37 litre water bath and an 18kg ice bank, it is suitable for pubs, bars, restaurants, brewery taprooms, event bars and larger home bar installations.

The cooler is designed for use with a suitable python system, helping to maintain product temperature through the beer lines on longer runs between the cooler and dispense point.

Its stainless steel construction and castors make it suitable for commercial installations while allowing easier positioning and access when required.

Key Features

• 6 product cooling coils
• Suitable for multi-product draught dispense systems
• Designed for use with python/remote beer dispense systems
• 37 litre insulated water bath
• 18kg ice bank capacity
• Stainless steel construction
• Castor mounted for easier positioning
• Suitable for beer, lager, cider and other suitable chilled beverages
• Ideal for pubs, bars, restaurants, brewery taprooms and event setups

Technical Specifications

Model: T120V
Cooling coils: 6
Water bath capacity: 37 litres
Ice bank: 18 kg
Cooling power: 781 W (672 Kcal/h)
Compressor: 9.04 cc (1/3 HP)
Power consumption: 450 W
Net weight: 40 kg

Dimensions:
Height: 790 mm
Width: 420 mm
Depth: 470 mm

Installation & Ventilation

Beer coolers generate heat during operation and require adequate airflow around the unit.

The cooler should be installed in a well-ventilated position with sufficient space around the unit to allow heat to escape. Do not obstruct the ventilation openings or install the cooler in a tightly enclosed space, as restricted airflow can reduce cooling performance and may cause the unit to overheat.

Allow sufficient space around the cooler for ventilation, pipework and access for servicing.

For best performance, the cooler should be correctly installed with suitable python insulation and recirculation appropriate to the dispense system.

Choosing the Right Beer Cooler

The Midi Remote 6 Coil is designed for larger or multi-product draught beer installations where several products need to be cooled.

Choosing the correct cooler depends on several factors, including the number of products being dispensed, the length of the python run, ambient temperature, required cooling capacity and expected throughput.

If you're unsure whether this cooler is suitable for your installation, please contact us before ordering and we'll be happy to advise.

Delivery

Due to the size and weight of this cooler, delivery is by pallet service rather than standard parcel courier.

Please ensure someone is available to accept delivery and that suitable access is available for the pallet.

Collection is also available from our Sunderland premises.

Manufacturer's Warranty

This cooler is supplied with a 12-month manufacturer's warranty.

The manufacturer's warranty is operated on a return-to-base basis. In the event of a warranty claim, the cooler may need to be returned in accordance with the manufacturer's warranty procedure for inspection and/or repair. Under the manufacturer's return-to-base warranty terms, the customer is responsible for the cost of transporting the cooler to the nominated repair or service location.
